Valves and Piping parts
A wide variety of valve and piping parts that have superior compatibility
A wide variety of valve and piping parts that have superior compatibility
Two-way Valves
PowChange Grain Automatic Y-shaped Model (PC-GYA)
Applications
Conveyor chute switching for granules and powders such as grains and raw materials
Specifications
⚫︎Materials:
Steel or stainless steel (powder-contacting areas)
⚫︎Damper seal Materials: Polyester elastomer
⚫︎Standard equipment:
Pneumatic cylinder, solenoid valve, and cylinder switch.
⚫︎Turnout angle specification of 45° (GLA model only)
⚫︎Flange: Equivalent to JIS5K
⚫︎Options:
Explosion specifications, secondary battery specifications, surface treatment(adhesion prevention, curing treatment, buffed finish etc.)
⚫︎Surface treatment:
Inner surface (under size PC-GYA-150A) ― Plated finish
Inner surface (over size PC-GYA-200A) ― Clear (Complies with Food Sanitation Law)
Outer surface ― N-9 white
Steel or stainless steel (powder-contacting areas)
⚫︎Damper seal Materials: Polyester elastomer
⚫︎Standard equipment:
Pneumatic cylinder, solenoid valve, and cylinder switch.
⚫︎Turnout angle specification of 45° (GLA model only)
⚫︎Flange: Equivalent to JIS5K
⚫︎Options:
Explosion specifications, secondary battery specifications, surface treatment(adhesion prevention, curing treatment, buffed finish etc.)
⚫︎Surface treatment:
Inner surface (under size PC-GYA-150A) ― Plated finish
Inner surface (over size PC-GYA-200A) ― Clear (Complies with Food Sanitation Law)
Outer surface ― N-9 white
⚫︎Final S indicates stainless steel (powder-contacting areas)
⚫︎When ordering, please provide us with the following information:
1.Model 2.Solenoid valve specifications 3.Cylinder switch voltage and quantity 4.Conveyed material and conveyance method
⚫︎When ordering, please provide us with the following information:
1.Model 2.Solenoid valve specifications 3.Cylinder switch voltage and quantity 4.Conveyed material and conveyance method
